The Trimble LSI GS010 crane boom angle sensor will accurately measure crane boom angle in independent mobile crane applications or as a complete crane warning system for most lattice boom cranes. The GS010 angle sensor has neither moving parts nor liquid that can interfere with the boom angle measurement. It is temperature compensated for maximum accuracy and is self leveling in its design. The Trimble GS010 angle sensor comes with tapped mounting blacks in place, you can simply place the boom or structure at zero degrees and adjust the angle sensor until you see the green light flash. The green light indicates that the GS 010 is level. At that point, the only thing left to do is tighten it down and it’s done. You won’t need to move the boom or structure to a high angle to do a span calibration. This feature is designed to eliminate the hassle and save time and money.
Trimble LSI GS010 Angle Sensor Brochure
Download Brochure Here
Features:
- No moving parts, uses electronic chip
- Direct Sequence-Spread Spectrum-Two Way Communication
- Transmission Range: 4,300 feet; 1,300 meters
- Ships as standard with 1-"D" Cell lithium battery, 2-4 years battery life
- Users can replace lithium battery with "D" Cell alkaline battery if lithium replacement battery is unavailable when battery goes low. Battery life is 6 months to 1 year using alkaline
- Stainless steel housing
- Easy calibration, bring boom to zero degrees, angle sensor has leveling light for zero degree calibration. No need to move boom to high angle for calibration
- 3/10th's of a degree resolution
- Potted electronics for increased water proof protection
- Operating temperature: -30F to +180F; -35C to +85
- 2 year warranty against defects
- Sensor can be left hand or right hand cab mounted, will automatically adjust for the side it is installed on
- Ideal for monitoring: Main Boom, Luffing Jib, Live Mast, Barge List Angle, Custom Applications
- Standard operating range is -180 degrees to +130 degrees, barge list angle sensor with a range from -5 degrees to +5 degrees
Can also be ordered as a 360 degree sensor
Trimble GS010-01 International Shipping Statistics
- ECCN: EAR99
- SCHEDULE B: 8423890000
- HTSUS CODE: 8423901000
- INTRASTAT: 9031802000
- COUNTRY OF ORIGIN: USA
- WEIGH: 1.8 KG
- SIZE: PLEASE SEE BROCHURE ABOVE
