003-100-210-012 Weight & Chain PAT Hirschmann

Code: 003-100-210-012

$ 349.00

In Stock

Quantity

Category: Anti Two Block, Hirschmann Featured Home Page, PAT Hirschmann Anti Two Block A2B

100% ORIGINAL AND QUALITY
24 MONTHS GUARANTEE
1-4 DAYS DELIVERY

Description
Contact Us

Weight and Chain assembly for use with PAT Hirschmann anti two block systems. Note, this includes the weight & chain only, anti two block switch is not included. Please contact us directly if you need assistance with identifying a specific A2B switch.

Manufacturer Description

WEIGHT & CHAIN, A2B w/o SHACKL E, 15.5lb/14lb WEIGHT 30”CHAIN INCLUDING: 031‐300‐100‐037 1 HARDWARE, CHAIN CONNECTOR QUICK LINK, 2 7/16"

Manufacturer Description

WEIGHT & CHAIN, A2B w/o SHACKL E, 15.5lb/14lb WEIGHT 30”CHAIN INCLUDING: 031‐300‐100‐037 1 HARDWARE, CHAIN CONNECTOR QUICK LINK, 2 7/16"
